Skid loader GTM x Rippa GT-03

The GTM x Rippa GT-03 Skid Loader is a compact, agile, and highly efficient machine engineered for demanding work in landscaping, agriculture, construction, and property maintenance. Despite its small frame, the GT-03 delivers impressive hydraulic power, excellent maneuverability, and reliable performance in tight or hard-to-reach areas. Equipped with a fuel-efficient B&S XR2100 gasoline engine and a durable hydraulic system, this loader ensures smooth operation, versatility, and long-lasting productivity.

Key Features

Engine:
Powerful Briggs & Stratton XR2100 gasoline engine, producing up to 13.6 HP with low fuel consumption and stable performance for continuous operation.

Hydraulics:
Reliable hydraulic system with a gear-type PGP51044SLP pump and high-quality components ensuring smooth response, strong lifting capability, and compatibility with multiple attachments.

Compact Design:
Narrow profile and tight turning radius allow the GT-03 to navigate barns, backyards, construction sites, and other confined workspaces with ease.

Versatility:
Supports a wide range of tools such as buckets, augers, trenchers, forks, and more—ideal for digging, grading, loading, hauling, and site maintenance.

Durability:
Built with a rugged steel frame and high-quality mechanical components, ensuring durability in challenging environments and reduced maintenance needs.

Ease of Operation:
Intuitive, user-friendly controls make the machine suitable for both beginners and experienced operators who require precise, efficient handling.

Specifications

Basic Performance

• Operating Weight: 1,598 lbs / 725 kg
• Bucket Capacity: 5.30 ft³ / 0.15 m³
• Rated Load (Safe Load): 308.65 lb / 140 kg
• Maximum Load: 617.29 lb / 280 kg
• Travel Speed: 0–2.5 km/h
• Gradeability: 25%
• Ground Pressure: 22.5 kPa
• Dumping Height: 61.14 in / 1553 mm
• Lifting Height: 88.94 in / 2259 mm
• Dumping Distance: 24.41 in / 620 mm
• Ground Clearance: 5.08 in / 129 mm

Engine

• Model: B&S XR2100
• Maximum Horsepower: 13.6 HP
• Power Output: 10 kW
• Max Speed: 3600 rpm
• Displacement: 0.42 L
• Cooling: Air-cooled
• Fuel Type: Gasoline (92#)
• Fuel Consumption: 0.8–1.2 L/h

Hydraulic System

• Main Pump: Gear pump PGP51044SLP
• Multi-way Valve: Tengfei
• Travel Motor: Luko BM5-250

Dimensions

• Transport Length (with bucket): 82.68 in / 2100 mm
• Transport Length (without bucket): 64.49 in / 1638 mm
• Width: 45.28 in / 1150 mm
• Height: 53.58 in / 1361 mm
• Bucket Width: 45.28 in / 1150 mm

* Accessories are not included in the price.
